12V 17A 200W LED Power Supply, Mean Well LRS-200-12
  • 12V 17A 200W LED Power Supply, Mean Well LRS-200-12
  • 12V 17A 200W LED Power Supply, Mean Well LRS-200-12
  • 12V 17A 200W LED Power Supply, Mean Well LRS-200-12
  • 12V 17A 200W LED Power Supply, Mean Well LRS-200-12
  • 12V 17A 200W LED Power Supply, Mean Well LRS-200-12
View All photos
12V 17A 200W LED Power Supply, Mean Well LRS-200-12
Model: LRS-200-12
  • Quantity
  • $33.00



    12V 17A 200Watt LED Power Supply, Mean Well LRS-200-12, UL Listed

    Mean Well LRS-200-12 is a metal enclosed 200 Watts AC DC power supply, providing constant voltage 12V 17 amp DC power for 12V LED strip lights and other LED lighting. Economy wise, it can work as a reliable and economical 12V 15 amp power supply. In addition to the high efficiency up to 89%, its metal enclosure greatly enhances heat dissipation, together with optimal design of free air convection, enabling the LRS-200-12 to work on full load in the temperature range -25 ~ +70°C (-13°F ~ +158°F).

    It has a low-profile design (30mm, 1.18in). It has extremely low no-load power consumption and complies with UL62368-1 safety, making it easy to pass various design and installation requirements. LRS-200 has complete protection functions and resistance to 5G vibration, providing a cost-effective power solution for various residential and commercial applications.

    Easy installation and suitable for North America and Europe

    It is easy to install this 12V power supply. When installing power supply for AC side, use our three prong wall plug cord to plug into an outlet or socket, or use wire cables(14AWG wire or 16AWG wire) to hard wire the power supply to AC source. For DC side, For DC side, connect to LED strip lights or LED controllers using wires (16AWG, 18AWG, or 20AWG wire, depending on length and current load).

    This 12V power supply is suitable for installation in North America and Europe. It has an input voltage selection to switch to 115V(also referred to as 110V or 120V) or 230V( 220V or 240V).

    Product Features

    • MEAN WELL LRS-200-12 1U low profile(30mm, 1.18in), enclosed power supply
    • AC input: 90~132Vac / 180~264Vac selectable by switch (suitable for 120/240Vac)
    • Output Voltage: Constant 12V DC
    • Operating Temperature: -25 ~ +70°C (-13°F ~ +158°F)
    • Rating: UL listed, CE
    • Protections: short circuit / over load / over voltage / over temperature
    • Withstand 300Vac surge input for 5 seconds
    • No load power consumption: less than 0.75W
    • Cooling: Metal enclosure, Free air convection
    • Withstand 5G vibration test
    • Operate on up to 5,000 meter altitude
    • Power on LED indicator
    • High efficiency, highly reliable
    • 100% full load aging test
    • MEAN WELL 3 year warranty

    If you need other 12V LED power supplies, please see the 12V LED power supply series.

    Specifications


      Model:  LRS-200-12
      Type:  Constant Voltage
      Waterproof:  IP20, non-waterproof
      Max Power:  204 Watts
      Input Voltage:  120 VAC or 240VAC
      Output Voltage:  12V DC
      Output Current:  17 Amps max.
      Working Temp. :  -25 ~ +70°C (-13 ~ +158°F)
      Manufacturer:  Mean Well
      Rating:  UL, CE
      Dimension:  215x115x30mm (L*W*H)/8.46x4.53x1.18in
      Warranty:  3 Years
