Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
  • Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
View All photos
Smart WiFi LED Dimmer Switch for Dimmable LED Strip Lights, Multi Zone
Model: wifi-dim-kit
  • Quantity
  • $65.00


    Qty Discounts New Price
    1-5$65.00
    6-10$62.00
    11+$59.00

    Smart WiFi LED Dimmer Switch, Multi Zone

    This WiFi LED dimmer is a popular smart dimmer switch that offers not only the basic function of optimal dimming for 12V and 24V DC dimmable LED strip lights, but also more advanced and intelligent features of lighting control than RF wireless dimmer. Via WiFi or 4G network, the WiFi dimmer is compatible with Google Assistant, Google Home, Alexa, and other intelligent lighting control system. Use your smartphone to dim the light strips to the desired brightness by voice control or a touch.

    With the controller App, WiFi dimmers have many more functions than RF dimmers. With the timer function, the dimmer can turn on and off the lights at the time you wish, according to your lifestyle. Integrated with smart home control, WiFi dimmers can easily create the perfect level of ambient lighting for any occasion without flickering.

    Use the 4G network smartphone to turn on the light on your way home, turn off the lights that were forgotten when your left. The WiFi dimmer provides two-way data communication, which allows you to know the light status at any time.

    With WiFi dimmers, setting up or making changes in multi zone lighting is much easier than with RF dimmers. WiFi dimmers easily support flexible zone setup via the controller software, just moving dimmer controls into different groups within the software. With RF dimmers, there is the pairing process only by which the remote control is able to be wirelessly connected with dimmers.

    WiFi wireless dimmers can be installed close to the lights. It reduces wiring work and simplifies your LED strip light installation, saving labor and time.

    This WiFi dimmer is a multi-purpose, five-channel LED controller. It not only controls single color lights, such as Warm White, Neutral White, Cool White, Red, Blue LED strip lights, but also can be used for Tunable White, RGB, RGBW, RGB+CCT light strips. So it is called 5-in-1 Controller Receiver. All of these different types of LED strips can be easily controlled via the controller software on your smartphone.

    This kit is ready for installation, items included:

    • A Wireless LED Dimmer Controller (5-in-1 Receiver), 6 Amps/CH, 15Amps total max output.
    • A 2.4G Gateway WiFi Transmitter.

    Product Features

    • Place the WiFi transmitter within 100 ft (30 meters) from the dimmer controller.
    • Use smartphone or tablet to control lights via WiFi or 4G network any time and anywhere.
    • The controller App for smartphone or tablet is free download, and easy to install on Apple iOS or Android system.
    • Wireless control signal goes through walls, no line of sight needed.
    • WiFi Transmitter Input: DC5V/500mA (Micro USB). USB power cable is included.
    • Controller Input Voltage: 12 or 24 DC.
    • Controller Output Voltage: 12 or 24 DC.
    • Controller Output Amp: 6A per channel, total 15A max.
    • Controller Output Power (Watts): 180W or 360W

    If you are setting up multi zone WiFi LED lighting, you need to buy multiple 5-in-1 Controller Receivers.

    For more choices, please see LED dimmer series.

    Specifications


      Model:  wifi-dim-kit
      Type:  WiFi, RF Wireless
      Input Voltage:  12V or 24V DC
      Light Color:  White, or Single Colored
      Output Channels:  5 CH
      Max Amps:  6A/CH, total 15A max.
      Output Voltage:  12V or 24V DC
      Output Wattage:  180W or 360W
      Dimensions:  124x37x23mm (4.9 x 1.45 x 0.9in)
      WiFi Gateway Volt:  5VDC (MicroUSB power cable included)
      WiFi Gateway Size:  90x66x15mm (3.54 x 2.6 x 0.59in)
      Rating:  CE, RoHS
      Waterproof:  IP20
      Warranty:  1 Year
